Standard-Servo Mks HV777A+ MG digital – Top-Angebote

Product

HV777

HV777A+

Torque

28 kg-cm (6.0V)

36.5 kg-cm (7.4V)

38 kg-cm (8.2V)

29.5 kg-cm (6.0V)

36.5 kg-cm (7.4V)

40.4 kg-cm (8.2V)

Geschwindigkeit

0.14 s (6.0V)

0.11 s (7.4V)

0.10 s (8.2V)

0.13 s (6.0V)

0.11 s (7.4V)

0.10 s (8.2V)

Gewicht

81.4g

75.45g

Abmessungen

40 x 20 x 45 mm

40 x 20 x 40 mm

Betriebsspannung

4.8 ~ 8.4 V DC Volts

(2S Lipo un-regulated )

4.8~8.4 V DC Volts

(2S Lipo un-regulated)

Working Frequency (Arbeitsfrequenz)

1520μs / 333Hz

1520μs / 333Hz

Dead Band

0.0008ms (Default)

0.0008ms (Default)

Bearing Type

2* Ball Bearing

2* Ball Bearing

Motor Typ

Japan High Quality Coreless Motor

Japan High Quality Coreless Motor

Gear Type

Metal Alloy Gear

Metal Alloy Gear
